1FK2104-4AK10-1MA0 Siemens

Description

The Siemens SIMOTICS S-1FK2 Servo Motor (1FK2104-4AK10-1MA0) is a high-dynamic, permanent-magnet synchronous motor engineered for precision motion control applications. Designed for use with SINAMICS S210 servo drives, it delivers smooth, accurate performance with a rated power of 0.60 kW, rated torque of 0.95 Nm, and up to 6,000 rpm rated speed. The motor provides excellent acceleration thanks to its low rotor inertia (0.4300 kgcm²) and supports demanding machine cycles.

Built with IP64 protection and natural cooling, it ensures reliable operation in industrial environments. The motor features an AM22DQC absolute encoder with 22-bit single-turn and 12-bit multiturn resolution for high-precision feedback. Mechanical features include a compact design, IM B5 mounting, 19 mm shaft with keyway, and 80 mm flange size.

For safety and positioning stability, it integrates a holding brake delivering 3.30 Nm holding torque with fast response times. Weighing only 2.9 kg, the motor is ideal for robotics, packaging machines, pick-and-place systems, and other high-speed automation tasks.
