3RW5950-0CH00 Siemens Communication Module

Description

The Siemens 3RW5950-0CH00 is a SIRIUS PROFINET High-Feature Communication Module designed for advanced network integration of SIRIUS 3RW55 soft starters. It provides a reliable and efficient interface for PROFINET industrial Ethernet communication, enabling remote control, diagnostics, and parameterization of connected devices.

Equipped with an integrated 2-port switch, the module allows easy line or ring topology configurations in automation networks. It supports seamless integration into Totally Integrated Automation (TIA Portal) environments, providing high-speed data exchange and compatibility with Siemens industrial controllers.

Built to industrial standards, it features a robust IP20-rated housing, operates within a wide temperature range of −25°C to +60°C, and can be installed at altitudes up to 5,000 meters. The module is compact and lightweight, ensuring easy mounting alongside the soft starter.

Key Technical Features:

• Product Series: Siemens SIRIUS 3RW59

• Type: PROFINET High-Feature Communication Module

• For Use With: SIRIUS 3RW55 Soft Starters

• Communication Interface: PROFINET (with integrated switch)

• Mounting: Screw fixing (any position)

• Protection Class: IP20 (finger-safe front)

• Operating Voltage: Supplied through the soft starter

• Operating Temperature: −25°C to +60°C

• Installation Altitude: Up to 5,000 m

• Dimensions (H×W×D): 126 × 28 × 82 mm

• Weight: 0.124 kg

• Certifications: CE, UL, CSA, KC, EMC compliant

The 3RW5950-0CH00 enables advanced communication and monitoring for SIRIUS 3RW55 soft starters, making it ideal for networked motor control systems in automation, manufacturing, and energy management applications.
