6EP1332-1SH71 Siemens

Description

The Siemens 6EP1332-1SH71 PM1207 is a high-quality stabilized power supply module engineered for SIMATIC S7-1200 PLC systems, offering dependable 24 V DC / 2.5 A output power. Designed with automatic 120/230 V AC input selection, the module ensures compatibility with a wide range of industrial power environments. Its regulated, isolated DC output guarantees stable voltage supply with minimal ripple and no start-up overshoot, making it ideal for sensitive automation electronics.

Equipped with robust protection features—including short-circuit protection, constant-current behavior, overload handling, and built-in overvoltage protection—the PM1207 enhances system reliability and safety. It supports parallel operation for increased power capacity and provides rapid response times under load changes. With an efficiency rating of 83%, a long MTBF of over 1.49 million hours, and approvals such as CE, UL, ATEX, IECEx, and marine certifications, it is suited for demanding industrial applications.

The compact 70 × 100 × 75 mm design enables easy DIN-rail mounting, and the IP20 enclosure ensures safe integration in control cabinets. Its broad operating temperature range (0°C to 60°C) and strong EMC compliance further support its reliability in challenging environments.
