6ES7510-1DJ01-0AB0 siemens

Description

The Siemens SIMATIC CPU 1510SP-1 PN (6ES7510-1DJ01-0AB0) is a high-performance, modular PLC designed for the ET 200SP distributed automation platform. It features 100 KB program memory and 750 KB data memory, supported by a SIMATIC memory card for additional storage. With 72 ns bit processing time, this CPU delivers fast execution for a wide range of automation tasks.

The integrated PROFINET IRT interface with a 3-port switch enables deterministic communication, media redundancy, and connections to up to 64 IO devices. The CPU also supports OPC UA client/server, web server access, MODBUS TCP, S7 communication, and advanced diagnostics via an onboard diagnostic buffer.

This CPU enables multi-hot swapping, isochronous mode operation, technology objects for motion control, PID control, high-speed counters, and flexible engineering through TIA Portal starting from version V17. It supports a wide range of distributed I/O modules, PROFIBUS (via CM), and offers extensive retentive memory, clock synchronization, and secure communication with TLS and HTTPS.

With compact dimensions (100 × 117 × 75 mm), robust operation up to 60°C, and installation capability up to 5000 m altitude, the CPU is well-suited for industrial environments requiring reliability, scalability, and modern communication standards.
