6ES7512-1DK01-0AB0 siemens

Description

The Siemens SIMATIC CPU 1512SP-1 PN (6ES7512-1DK01-0AB0) is a powerful, modular controller designed for the ET 200SP distributed I/O system, offering exceptional processing speed and high communication performance.
It includes 200 KB program memory, 1 MB data memory, and supports an external SIMATIC memory card (up to 32 GB) for load memory. The CPU operates on 24 V DC, features reverse polarity protection, and has a typical power loss of only 5.6 W.

With a 48 ns bit processing speed, this CPU delivers rapid execution for demanding automation tasks. It supports hot swapping, isochronous mode, and advanced engineering via TIA Portal V17 or newer. The integrated PROFINET interface with a 3-port switch allows seamless networking, IRT communication, and connection of up to 128 IO devices. Optional PROFIBUS communication is supported through a CM DP module.

The controller supports extensive diagnostic features, web server access, OPC UA server/client capabilities, motion control functions (up to multiple axes), and a wide range of programming languages including LAD, FBD, STL, SCL, GRAPH.
Built for industrial reliability, it operates from –25°C to +60°C, at altitudes up to 5000 m, and includes comprehensive security functions such as access protection, block protection, and encrypted communication.

This CPU is designed for mid-range automation applications requiring high performance, flexible communication, and modular scalability within the ET 200SP platform.
